ALTUS Nexto NX3004 User Manual

4. Configuration
128
recommended to use
the project name that
is loaded in the PLC.
STRING with
numbers or with “_”. It
allows up to 49
characters.
Gateway Address
IP Address of the
computer that the
OPC Server is
installed, for the
cases in which all
PLCs are in the same
subnetwork. If there’s
some PLC that it’s in
another subnetwork,
it must be specified
the Gateway used in
that subnetwork.
127.0.0.1
0.0.0.0 to
255.255.255.255
Gateway Port
TCP Port for the
connection with the
Gateway.
1217
2 to 65534
Device Name
It’s the PLC name
displayed in the
communication
Settings tab. The
name is the STRING
before the
hexadecimal value
that is between [ ].
Enabled only when
the checkbox Use
TCP/IP
Blockdriver is not
selected.
‘0000’
This field is a
STRING and it
accepts any
characters, as done in
the PLC name
configuration in the
Device
Communication
Setting tab. It allows
up to 49 characters.
IP Address Active
IP address of the
PLC. Enabled only
when the checkbox
Use TCP/IP
Blockdriver is
selected. It is used
only when the setting
is not redundant.
192.168.15.1
0.0.0.0 to
255.255.255.255
IP Address PLC A
IP address of the
CPA. Enabled only
when the
configuration is
redundant. It is the
primary PLC address
to which the server
will communicate if
there is no failure.
192.168.15.69
0.0.0.0 to
255.255.255.255
IP Address PLC B
IP address of the
CPB. Enabled only
when the
configuration is
redundant. It is the
secondary PLC
address to which the
server will
communicate if a
failure occurs.
192.168.15.70
0.0.0.0 to
255.255.255.255
Device Port
TCP Port. Enabled
only when the
checkbox Use
TCP/IP
Blockdriver is
selected.
11740
11740 or 11739
Table 4-88. Configuration Parameter of each PLC for the OPC Server
