4. Configuration
142
The Information tab, present on the EtherCAT Master configuration editor, shows, if available, the
following general information about the module: Name, Vendor, Type, Version Number, Category,
Order Number, Description, Image.
EtherCAT Slave Configuration
Below are listed the main EtherCAT Slave configuration options, as defined in the Device
Description File.
Slave Parameters
Below are presented the general parameters found in EtherCAT Slave configuration initial screen.
This field is only available if the Autoconfig mode (Master) isn’t enabled.
Figure 4-53. EtherCAT Slave Configuration Dialog
Autoincremental Address
(16-bit) defined by the
Slave position in the
