4. Configuration
143
Slave final address,
assign by the Master
during startup. This
address is independent
from the position in the
network.
Enable the Slave
advanced Settings
options.
Declare the Slave as
Optional.
Show all Distributed Clock
configurations provided by
the device description file
Enable the Distributed
Clock configuration
options.
Show the Cycle Time set
in Master
Enable the Sync 0
synchronization unit
configurations.
By selecting this option,
the Cycle Time will be
determined by the product
of the factor and the Sync
Unit Cycle.
If this option is selected,
the desired time, in
microseconds, can be
directly set into the Cycle
Time (µs) field.
Show the cycle time
currently set.
Time between the sync
events and the “Output
Valid” or “Input Latch”
time.
-2147483648 to
2147483647
Enable the Sync 1
synchronization unit
configurations.
By selecting this option,
the Cycle Time will be
determined by the product
of the factor and the Sync
Unit Cycle.
If this option is selected,
the desired time, in
microseconds, can be
directly set into the Cycle
Time (µs) field.
Show the cycle time
currently set.
Time between the sync
events and the “Output
Valid” or “Input Latch”
time.
-2147483648 to
2147483647
If unmarked, it will disable
the Vendor ID Check
If unmarked, it will disable
the Product ID Check
