4. Configuration
225
Warm Start Counter:
It will only be incremented during energization
sequence of the system and not due to the Reset
Warm command of MasterTool IEC XE (0 to 65535)
Counter of disorders smaller than the time of power
failure to support the CPU (0 to 65535)
Reset counter made by the RTS (Runtime System)
(0 to 65535)
CPU reboot due to a power supply failure in the last
initialization
CPU reboot due to watchdog active in the last
initialization
Alarm generated due to internal temperature be in 0°
C or below
Alarm generated due to internal temperature be in
85° C or above
Modbus RTU via TCP Client
Modbus RTU via TCP Server
Modbus RTU via TCP Client
Modbus RTU via TCP Server
Reports the operating status of the CPU:
01: All user applications are in Start Mode
03: All user applications are in Stop Mode
There are one or more forced IO points
Indicates which server is active:
00: No server active
01: Primary server active
02: Secondary server active
Counter of how many times primary server was
unavailable (0 to 65535)
Counter of how many times secondary server was
unavailable (0 to 65535)
Counter of times the RTC has been updated by the
NTP service (0-4294967295)
Indicates status of last update:
00: Not updated
01: Last update failed
02: Last update had success
Indicates which server was used in the last update:
00: Any update
01: Primary Server
02: Secondary Server
Minute of last RTC update
Seconds of last RTC update
LastUpdateTimeMilliSeconds
Milliseconds of last RTC update
Connection status of client 01
Client 01 event queue status:
FALSE – OK
TRUE – Queue limit exceeded
Client 01 event counter on queue
