CPU Direct Representation Variable
DG_Modulo.tDetailed.*
AT Variable
Indicates if the memory used for
recording user files is able to
receive data.
Free memory space for user files
in Kbytes.
Storage capacity of the memory of
user files in Kbytes.
Table 7-19. UserFiles Detailed Diagnostics Group Description
Note:
User Partition: The user partition is a memory area reserved for the storage of data in the CPU. For
example: files with PDF extension, files with DOC extension and other data.
CPU Direct Representation Variable
DG_Modulo.tDetailed.*
AT Variable
Status of memory in which are
inserted the user logs.
Free space in the memory of user
logs in Kbytes.
Storage capacity of the memory of
user logs in Kbytes.
Table 7-20. UserLogs Detailed Diagnostics Group Description
CPU Direct Representation Variable
DG_Modulo.tDetailed.*
AT Variable
Status of the Memory Card:
00: Memory card not mounted
01: Memory card inserted and
mounted
MemoryCard.
bMemcardtoCPUEnable
d
Protection level of the Memory
Card:
Data reading of the memory card
by the authorized CPU.
MemoryCard.
bCPUtoMemcardEnable
d
Data writing in the memory card
by the authorized CPU.
MemoryCard.
dwFreeSpacekB
Free space in the Memory Card in
Kbytes.
MemoryCard.
dwTotalSizekB
Storage capacity of the Memory
Card in Kbytes.
Table 7-21. MemoryCard Detailed Diagnostics Group Description
CPU Direct Representation Variable
DG_Modulo.tDetailed.*
AT Variable
WHSB.
byHotSwapAndStartupS
tatus
Informs the abnormal situation in
the bus which caused the
application stop for each mode of
hot swapping. See Table 7-23 for
more information
