4. Configuration
76
When true indicates that an operation command without
select was received.
When true indicates that a command, which doesn’t require
the receiving acknowledge, was received.
When true indicates that an operation command activated
by time was received.
Programming of the instant in which it must be runned the
command. This field is valid only when bTimedOperate is
true.
When true indicates that the received command was sent
only for test, as so the command must not be runned.
Table 4-35. Parameters sOperateConfig
Informs the type of the received command:
NO_COMMAND(0)
SINGLE_POINT_COMMAND(1)
DOUBLE_POINT_COMMAND(2)
INTEGER_STATUS_COMMAND(3)
ENUMERATED_STATUS_COMMAND(4)
ANALOGUE_VALUE_COMMAND(5)
When a command is received, in received command type
function, defined by eParamType, the corresponding data
structure is filled. This structures parameters are described
on Table 4-37 to Table 4-41
Table 4-36. Parameters sValue
The pulsed command configuration parameters are stored in
this structure. This structure parameters are described on
Table 4-42
Table 4-37. Parameters sSinglePoint
The pulsed command configuration parameters are stored in
this structure. This structure parameters are described on
Table 4-42
Table 4-38. Parameters sDoublePoint
Table 4-39. Parameters sIntegerStatus
