7.2 Common Commands
7-7
7
Remote Commands
:SYSTem:CONDition:USB?
Response <usb1>,…,<usb127>=<STRING RESPONSE DATA>
“XXXX” Model Name Example: MP1861A
Refer to Table 7.2.1-2 “Option character
correspondence table”.
Function Queries USB module model name.
Example > :SYSTem:CONDition:USB?
< MP1861A, MP1862A,NONE,NONE,…,NONE
Table 7.2.1-2 Option Character Correspondence Table
Model Name Option Number Option Name
MP1861A 56G/64Gbit/s MUX OPTx01 64Gbit/s Extension
OPTx11 Data Output(0.5 to 2.5 Vp-p)
OPTx13 Data Output (0.5 to 3.5 Vp-p)
OPTx30 Variable Data Delay
MP1862A 56G/64Gbit/s DEMUX OPTx01 64Gbit/s Extension
:SYSTem:CONDition?
Response "<mainframe>, <slot x>,...,<usb x>,..., <usb 127>"
<mainframe> Previous function omitted
<slot x> Previous function omitted
<usb x>=<module>,<serial>,<fpga1>[,<fpga2>],<boot>,<application>,<opt>
x indicates a USB number. The USB number is 1 to 127.
number as follows.
<module>=<STRING RESPONSE DATA>
XXXXXXXXX Module Name Example: MP1861A
Refer to Table 7.2.1-2 “Option Character
Correspondence Table”.
Note:
NONE is output if no option is installed.
<serial>=<STRING RESPONSE DATA>
XXXXXXXXXX 0000000000 to 9999999999
Serial number
Note:
"-------------" is output if no module is
installed.
<fpga1>[,<fpga2>,.....]=<STRING RESPONSE DATA>
XXXX.XX.XX 1.00.00 to 9999.99.99
FPGA version
<boot>=<STRING RESPONSE DATA>
XXXX.XX.XX 1.00.00 to 9999.99.99
Logic Boot version
