Chapter 7 Remote Commands
7-34
:DEMux:CALCulate:DATA:EALarm? <string>
Parameter <string>=<STRING PROGRAM DATA>
"CURRent:<result>" Current data
"LAST:<result>" Measurement end data
Refer to Table 7.3.2.1-3 for the <result> contents.
Response <string>=<STRING RESPONSE DATA>
Table 7.3.2.1-2 Response Format
Form Format Description
Form1
Integer type
"XXXXXXX" For 0 to 9999999
"X.XXXXEXX" For 1.0000E07 to 9.9999E16
"-------" When no data corresponds to the query
Form2
Fraction type
"X.XXXXE
–
XX" For 0.0000E
–
16 to 1.0000E00
"-------" When no data corresponds to the query
Form3
% type
"XXX.XXXXX" For 0.0000 to 100.0000
"-------" When no data corresponds to the query
Form4
Frequency type
"XXXXXXXXX" For 0 to MAX(Hz)
"---------" When no data corresponds to the query
Form5
Voltage type
"XX.XXX,XX.XXX" For
–
4.000 to +4.000(V)
"----,-----" When no data corresponds to the query
Form6
Phase type
"xxxxx,xxx.xx" mUI units, ps units
"-----,----" When no data corresponds to the query
Function Queries measured data for parameter.
Example To query the total error rate of the current data
> :DEMux:CALCulate:DATA:EALarm? "CURRent:ER:TOTal"
< :"0.0000E-16"
Compatibility Compatible with MU182040A and MU182041A.
Table 7.3.2.1-3 Parameter
Form <result> Format
Error Rate Total
INS
OMI
ER:TOTal
ER:INSertion
ER:OMISsion
Form2
Error Count Total
INS
OMI
EC:TOTal
EC:INSertion
EC:OMISsion
Form1
%EFI Total EFI:TOTal Form3
EI Total EI:TOTal Form1
Frequency (kHz) FREQuency Form4
Clock Count CC:TOTal Form1
Clock Alarm AINTerval:CALarm Form1
Sync Loss AINTerval:PSLoss Form1
