7.4 Automatic Measurement Commands
7-73
7
Remote Commands
:CALCulate:DATA:DIAGram? <slot>,<interface>,<string>[,<unit>]
Parameter <slot>=<CHARACTER PROGRAM DATA>
SLOT1 to SLOT6 Slots No. 1 to No. 6
USB11 to USB14 USB No.11 to 14
<interface>=<DECIMAL NUMERIC PROGRAM DATA>
1 to 4 Data1 to 4
Fixed to 1 if using a USB module
<string>=<STRING PROGRAM DATA>
<result> Measurement data
For details on <result>, refer to Table 7.12.10.2.2-3.
[<unit>]=<DECIMAL NUMERIC PROGRAM DATA>
1 to 4 Mainframe Nos. 1 to 4
When using two or more MT1810A units in serial connection, specify the
mainframe number.
Can be omitted. Mainframe No. 1 is specified when omitted.
Response <string>=<STRING RESPONSE DATA>
Table 7.4.3.2.2-2 Response Format
Type Format Description
Form1
Eye Map type
"XXXXX,YYYYY" XXXXX: Phase (mUI or ps)
Displayed in the selected unit.
YYYYY: Threshold (mV)
"-----,-----" When no data corresponds to the query
Function Queries the Eye Diagram measurement results of the specified slot and
point.
Table 7.4.3.2.2-3 Eye Diagram Measurement Items <result>
Item <result>
Response
Format
Eye
Map type
1E–3
1E–4
|
1E–11
1E–12
"MAP:E_3:POINt1",..,"MAP:E_3:POINt128"
"MAP:E_4:POINt1",..,"MAP:E_4:POINt18"
|
"MAP:E_11:POINt1",..,"MAP:E_11:POINt128"
"MAP:E_12:POINt1",..,"MAP:E_12:POINt128"
Form1
Example To query the Eye Diagram measurement results of USB No.11 and E-3
point:
>:CALCulate:DATA:DIAGram? SLOT1, 2,"MAP:E_3:POINt1"
<" 100, 1000"
Compatibility Incompatible with existing models.
