Table 3.2.2.3-1 Main Function Menu (RX Mode) Explanation (Cont’d)
Menu Display Function
Signal Output
Repeat
Restarts transmission output of modulation
wave signal.
3.8.1 “Setting modulation wave signal”
Signal Modulation
Sets modulation for output signal.
3.8.1 “Setting modulation wave signal”
Signal Output
Sets signal output On/Off.
3.8.1 “Setting modulation wave signal”
Average Not available in RX mode.
Marker Not available in RX mode.
Accessory
Performs settings for other functions.
5.1 “Selecting Other Functions”
3.2.2.4 RX mode (Audio Analyzer) screen
This section explains the main function menu on the RX mode screen
under the following conditions.
●
Neither the Analog Signal Generator (MS2830A-088/188) nor the
Analog Function Extension Option for Vector Signal Generator
(MS2830A-029/129) is installed.
●
The MS2830A-018/118 Audio Analyzer is installed.
F1
F2
F3
F4
F5
F6
F7
F8
Figure 3.2.2.4-1 RX Mode Main Function Menu
(Audio Analyzer Screen)
