Chapter 3 Measurement
3-20
3.2.2.5 RX mode (Audio Analyzer) + RF Signal Generator screen
This section explains the main function menu on the RX mode screen
under the following conditions.
● The Analog Signal Generator (MS2830A-088/188) or the Analog
Function Extension Option for Vector Signal Generator
(MS2830A-029/129) is installed.
● The MS2830A-018/118 Audio Analyzer is installed.
F1
F2
F3
F4
F5
F6
F7
F8
Figure 3.2.2.5-1 RX Mode Main Function Menu (Audio Analyzer +RF
Signal Generator Screen)
