Chapter 3 Measurement
3-48
3.4.8.2 Setting Frequency Domain graph
This section describes the settings for the Frequency Domain graph.
Press
(Frequency Domain Setting) on the Trace Function menu to
display the Frequency Domain Setting Function menu. The setting is
enabled when Frequency Domain is set to On.
Window Function
■
Summary
Sets a
window function
for the Frequency Domain graph.
■
Options
Rectangular Uses Rectangular window.
Hann Uses Hann window.
Blackman-Harris Uses Blackman-Harris window.
Hamming Uses Hamming window.
Flat Top Uses Flat Top window.
X-AXIS
■
Summary
Sets the horizontal scale (X-axis) on the Frequency Domain graph.
■
Options
Linear Display the horizontal scale in linear.
Log Display the horizontal scale in log.
Start Freq
■
Summary
Sets the minimum frequency for X-axis on the Frequency Domain
graph.
■
Setting range (X-AXIS is Linear)
10 to 49950 Hz
■
Options (X-AXIS is Log)
10 Hz Sets the minimum value of the X-axis scale to 10 Hz.
20 Hz Sets the minimum value of the X-axis scale to 20 Hz.
30 Hz Sets the minimum value of the X-axis scale to 30 Hz.
50 Hz Sets the minimum value of the X-axis scale to 50 Hz.
100 Hz Sets the minimum value of the X-axis scale to 100 Hz.
200 Hz Sets the minimum value of the X-axis scale to 200 Hz.
300 Hz Sets the minimum value of the X-axis scale to 300 Hz.
500 Hz Sets the minimum value of the X-axis scale to 500 Hz.
1 kHz Sets the minimum value of the X-axis scale to 1 kHz.
2 kHz Sets the minimum value of the X-axis scale to 2 k Hz.
3 kHz Sets the minimum value of the X-axis scale to 3 kHz.
5 kHz Sets the minimum value of the X-axis scale to 5 kHz.
10 kHz Sets the minimum value of the X-axis scale to 10 kHz.
