MS20xxC UG PN: 10580-00305 Rev. L B-1
Appendix B — Signal Standards
B-1 Introduction
This appendix provides a sample list of signal standards. This list can be used as a reference
when making measurements with the VNA Master.
Table B-1. Signal Standards
Signal Standard
Center
(MHz)
Span
(MHz)
Valid Channels
AMPS / EIA 553 - Uplink 859 70 1-799, 990-1023
AMPS / EIA 553 - Downlink 859 70 1-799, 990-1023
C-450 (P) - Uplink 463.5 21 1-800
C-450 (P) - Downlink 463.5 21 1-800
C-450 (SA) - Uplink 462.5 15 1-247
C-450 (SA) - Downlink 462.5 15 1-247
CDMA US Cellular - Uplink 859 70 1-799, 990-1023
CDMA US Cellular - Downlink 859 70 1-799, 990-1023
CDMA US PCS - Uplink 1920 140 1-1199
CDMA US PCS - Downlink 1920 140 1-1199
CDMA Korea PCS - Uplink 1810 120 1-599
CDMA Korea PCS - Downlink 1810 120 1-599
CDMA Japan / ARIB - Uplink 878.5 93 1-799, 801-1039, 1041-1199
CDMA Japan / ARIB - Downlink 878.5 93 1-799, 801-1039, 1041-1199
CDMA China - 1 - Uplink 916 88 0-1000, 1329-2047
CDMA China - 1 - Downlink 916 88 0-1000, 1329-2047
CDMA China - 2 - Uplink 910 76 0-1000
CDMA China - 2 - Downlink 910 76 0-1000
cdma2000 Class 0, Korea Cellular - Uplink 859 70 1-799, 990-1023
cdma2000 Class 0, Korea Cellular - Downlink 859 70 1-799, 990-1023
cdma2000 Class 0, N.A. Cellular - Uplink 859 70 1-799, 990-1023
cdma2000 Class 0, N.A. Cellular - Downlink 859 70 1-799, 990-1023
cdma2000 Class 1, N.A. PCS - Uplink 1920 140 0-1199
cdma2000 Class 1, N.A. PCS - Downlink 1920 140 0-1199
cdma2000 Class 2, (TACS Band) - Uplink 916 88 0-1100, 1329-2047
cdma2000 Class 2, (TACS Band) - Downlink 916 88 0-1100, 1329-2047
cdma2000 Class 3, (JTACS Band) - Uplink 878.5 93 1-799, 801-1039, 1041-1199
cdma2000 Class 3, (JTACS Band) - Downlink 878.5 93 1-799, 801-1039, 1041-1199
cdma2000 Class 4, Korea PCS - Uplink 1810 120 0-599
cdma2000 Class 4, Korea PCS - Downlink 1810 120 0-599
