Anritsu VNA Master MS2026C User Manual

Waveguide Data F-5 Waveguide Technical Data
MS20xxC UG PN: 10580-00305 Rev. L F-7
F-5 Waveguide Technical Data
Table F-6. Waveguide Offset Short
a
Specifications
a.Offset shorts are 3/8 wave at the geometric mean frequency waveguide band and dimensionally accurate
to <0.5 degree at the maximum operating frequency of the corresponding wavelength.
Offset Short P/N Frequency (GHz) Length (mm)
24UM70 6.926 20,710 +/- 0.08
24UM84 8.396 17,040 +/- 0.05
24UM100 10.084 14,675 +/- 0.05
24UM120 12.247 11,978 +/- 0.04
24UA187 4.807 30,979 +/- 0.11
24UA137 6.926 20,710 +/- 0.08
24UA112 8.396 17,040 +/- 0.05
24UA90 10.084 14,675 +/- 0.05
24UA62 14.940 9,742 +/- 0.04
24UA42 21.225 7,067 +/- 0.03
24CMR187 4.807 30,979 +/- 0.11
24CMR137 6.926 20,710 +/- 0.08
24CMR112 8.396 17,040 +/- 0.05
24CMR90 10.084 14,675 +/- 0.05
24UER70 6.926 20,710 +/- 0.08
24UER84 8.396 17,040 +/- 0.05
24UER100 10.084 14,675 +/- 0.05
