System Operations 6-10 Display Settings Menu
MS20xxC UG PN: 10580-00305 Rev. L 6-9
6-10 Display Settings Menu
Key Sequence: Shift, System (8)>System Options > Display
Brightness: Opens the “Brightness Settings Menu” on page 6-10.
Display Blank: Opens the message box illustrated in Figure 6-10. Press
Enter to turn off the display, or press Esc to abort. To turn the display back on,
press any key (except the Power button) three times in rapid succession. A
power cycle also turns the display back on.
Default Colors: Sets the display colors to the factory defaults. Used for
normal viewing.
Black on White: Sets the display colors to black on a white background.
Used for printing and viewing in broad daylight conditions.
Night Vision: Sets the display to a red-tinted color on a black background.
This setting is optimized for nighttime viewing.
High Contrast: Increases the black and white contrast of the default display.
This setting is used in challenging viewing conditions.
Color on White: Sets the display background to white, the grid to gray, and
leaves sweep data in color. This setting is used for printing and viewing in
broad daylight conditions.
Back: Press this key to return to the “System Options Menu” on page 6-8.
Figure 6-9. Display Settings Menu
Figure 6-10. Display Blank Message Box
Back
Display Settings
Default Colors
Black on White
Night Vision
High Contrast
Color on White
Brightness
Display Blank
To Next Page
