GPS Receiver, Option 31 7-3 Resetting GPS
MS20xxC UG PN: 10580-00305 Rev. L 7-3
7-3 Resetting GPS
To reset the GPS, press the Reset submenu key. The green GPS icon shows a red cross mark
when satellite tracking is lost after tracking four or more satellites. The GPS latitude and
longitude are saved in the instrument memory until the VNA Master is turned off or until
GPS is turned off by using the GPS On/Off key.
7-4 Saving and Recalling Traces with GPS Information
Saving Traces with GPS Information
The GPS coordinates of a location can be saved along with a measurement trace. Refer to
“Save Menu” on page 5-9 for more information. The current GPS coordinates will be saved
with the measurement traces whenever GPS is on and actively tracking satellites.
Recalling GPS Information
If the GPS coordinates were saved with a measurement, the coordinates will be recalled when
the measurement is recalled. Refer to “Recall Menu” on page 5-13 for more information on
recalling a saved trace.
Figure 7-3. GPS Icon, Tracking Lost
