6-6 Meas Gain Range Menu (VNA Mode) System Operations
6-6 PN: 10580-00305 Rev. L MS20xxC UG
6-6 Meas Gain Range Menu (VNA Mode)
Key Sequence: Shift, System (8)>Application Options > Meas Gain Range
6-7 Time Domain Options Menu (VNA Mode)
This menu is available only when Option 2, Time Domain, is installed. More information is
available in the Vector Network Analyzer Measurement Guide (listed in Appendix A).
Key Sequence: Shift, System (8)>Application Options > Time Domain
Auto: Press this key to set the Measurement Gain Range Mode to Auto. In
this mode, the instrument adjusts the gain automatically to provide the best
overall system performance (dynamic range and high level noise).
Fixed: Press this key to set the Measurement Gain Range Mode to Fixed. In
this mode, the gain of the instrument is always set to the low gain setting. For
most applications, Auto mode is recommended. For certain types of filter
measurements (mostly in the range less than 500 MHz), the instrument may
toggle between low gain and high gain modes as the signal level rises from
the noise to the pass band of the filter, resulting in extra ripple. Setting the
Gain Range to Fixed may address that problem.
Back: Press this key to return to the “Application Options Menu (VNA
Mode)”.
Figure 6-5. VNA Mode (Measurement Gain Range) Menu
Reflection Calc in Time
One Way Round Trip: Press this submenu key to toggle the setting for the
calculation method that is used in the time domain (not distance) reflection
measurements. The method can be either One Way (divide the total time
by 2) or Round Trip.
Gate Coupled
On Off: Press this key to toggle the gate coupling On or Off. When set to
On, the gate settings (start, stop, and so forth) for all traces are the same.
When set to Off, each trace has a gate whose settings are independent of any
of the other gates that are being used.
Domain Processing
Auto BP Only: Press this key to toggle domain processing to Auto or to
BP Only. In Auto, the instrument selects Low Pass processing whenever
possible and switches to Band Pass if not possible. In BP Only, the setting will
never be Low Pass.
Back: Press this key to return to the “Application Options Menu (VNA Mode)”
on page 6-5.
Figure 6-6. Application Options Menu (VNA Mode)
Back
Auto
Fixed
Mode
Back
Time Domain Options
Reflection Calc in Time
One Way Round Trip
Gate Coupled
On Off
Domain Processing
Auto BP Only
