6-13 System Options 2/2 Menu System Operations
6-12 PN: 10580-00305 Rev. L MS20xxC UG
6-13 System Options 2/2 Menu
Key Sequence: Shift, System (8)>System Options > More
Share CF & Pwr Offset
All Modes Not Shared: Press this submenu key to toggle the setting
between All Modes and Not Shared. Select All Modes to have the current
center frequency setting and power offset setting carried over when changing
measurement modes. This function is not applicable to measurements that do
not have a center frequency or power offset setting or to measurements in
which the current center frequency or power offset setting is outside the range
of the new measurement.
Note: This key is used only for spectrum analysis.
Set Remote Access Password: Press this submenu key to open the
Password text box (see Figure 6-15) and Text Entry menu. Passwords may
contain digits, uppercase and lowercase letters, and the symbols: - _ + .
(hyphen, underscore, plus, period). Press Enter to save or Esc to cancel.
Connecting to the instrument via Master Software Tools (v2.21.1 or later) will
require the set password. An empty Password field means the instrument is
not password-protected. The password is also removed following a Master
Reset, Factory Defaults reset, or a firmware update.
Power–On: Press this submenu key to display the “Power–On Menu”
on page 6-13.
Back: Press this submenu key to return to the “System Options Menu”
on page 6-8.
Figure 6-14. System Options 2/2 Menu
Warning
Do not set a remote access password when using SCPI commands to
communicate with the instrument.
Figure 6-15. Remote Access Password Text Box
Back
System Options 2/2
Share CF &
Pwr Offset
All Modes Not Shared
Set
Remote Access
Password
Power–On
