System Operations 6-5 Application Options Menu (VNA Mode)
MS20xxC UG PN: 10580-00305 Rev. L 6-5
6-5 Application Options Menu (VNA Mode)
This menu is specific to the VNA application.
Key Sequence: Shift, System (8)>Application Options
Standard VNA menus selected.
Units
mft:Press this submenu key to toggle the units setting to metric (meters,
or m) or to U.S. (feet, or ft). Press Enter to accept the changes, or press the
Esc key to return to normal operation without changing the setting.
External Reference: Press this key to toggle between the two choices of
turning Off the external reference or selecting the external reference.
Trace Label
On Off: Press this key to toggle the trace labels On or Off.
Meas Gain Range: Press this key to open the “Meas Gain Range Menu
(VNA Mode)” on page 6-6. Then select Auto or Fixed.
Time Domain
On Off: Press this submenu key to open the “Time Domain Options Menu
(VNA Mode)” on page 6-6.
Back: Press this key to return to the “System Menu” on page 6-4.
Figure 6-4. Application Options Menu (VNA Mode)
Back
Options
Units
m ft
Trace Label
On Off
Meas Gain Range
Auto
External Reference
Off 10 MHz
Time Domain
To Next Page
