MS20xxC UG PN: 10580-00305 Rev. L 8-1
Chapter 8 — Anritsu Tool Box
8-1 Introduction
The Anritsu Tool Box is a suite of applications that provide an interface between Anritsu
handheld RF instruments and a PC. The instrument connects to the computer via a USB,
Ethernet, or serial port. Depending on the application selected, available functions range
from the capture, transfer, and reporting of measurement data for trace analysis, to coverage
and interference mapping, and the delivery of work instructions.
Tool Box applications are available for download from the Anritsu website at
anritsu.com/en-US/test-measurement/support/technical-support/handheld-tools-tool-box.
Click the link to one of the Tool Box applications, then click Downloads and choose either the
Full Installer or Web Installer. There is no difference between the two if you run the installer
without saving. If you elect to save, the Full Installer will download all Anritsu software
needed in a single executable file, which allows you to perform the installation later on a
computer with no Internet access required. The Web Installer is a much smaller file that will
require Internet access to execute the software installation.
8-2 Software Installation
Whether running the installer directly or executing the saved file, follow the instructions on
screen. The Setup screen illustrated in Figure 8-1 may change with the software version.
You will be asked to select which applications you wish to install. Not all instrument models
are supported by every software tool. To view the list of instrument models supported by a
Tool Box application, click the Instruments tab on the application Web page.
Figure 8-1. Anritsu Tool Box Setup Wizard
