Anritsu VNA Master MS2026C User Manual

MS20xxC UG PN: 10580-00305 Rev. L E-1
Appendix E — Coaxial Cable
Technical Data
E-1 Coaxial Cable Technical Data
The table below provides a list of common coaxial cables.
Table E-1. Coaxial Cable Technical Data (Sheet 1 of 4)
Manufacturer Cable
Prop.
Vel.
Freq
1
Loss
1
Freq
2
Loss
2
Freq
3
Loss
3
Andrew FSJ1-50A (6 GHz) 0.84 1000 0.196 2500 0.313 6000 0.532
Andrew FSJ2-50 (6 GHz) 0.83 1000 0.133 2500 0.223 6000 0.374
Andrew FSJ4-50B (6 GHz) 0.81 1000 0.118 2500 0.201 6000 0.348
Andrew EFX2-50 (6 GHz) 0.85 1000 0.121 2500 0.202 6000 0.341
Andrew LDF1-50 (6 GHz) 0.86 6000 0.306 6000 0.306 6000 0.306
Andrew LDF2-50 (6 GHz) 0.88 6000 0.323 6000 0.323 6000 0.323
Andrew LDF4-50A (6 GHz) 0.88 1000 0.073 2500 0.121 6000 0.218
Andrew HJ4-50 (6 GHz) 0.914 1000 0.092 2500 0.156 6000 0.257
Andrew HJ4.5-50 (6 GHz) 0.92 1000 0.054 2500 0.089 6000 0.148
Andrew AVA5-50 7/8 0.91 1000 0.038 2000 0.055 2500 0.063
Andrew AVA7-50 1-5/8 0.92 1000 0.022 2000 0.034 2500 0.038
Andrew EFX2-50 0.85 1000 0.121 2000 0.177 2500 0.202
Andrew FLC 12-50J 0.88 1000 0.075 2000 0.11 2500 0.134
Andrew FLC 38-50J 0.88 1000 0.115 2000 0.169 2500 0.19
Andrew FLC 78-50J 0.88 1000 0.041 2000 0.061 2500 0.072
Andrew FLC 114-50J 0.88 1000 0.033 2000 0.05 2500 0.059
Andrew FLC 158-50J 0.88 1000 0.025 2000 0.038 2500 0.042
Andrew FSJ1-50A 0.84 1000 0.196 2000 0.285 2500 0.313
Andrew FSJ2-50 0.83 1000 0.133 2000 0.196 2500 0.223
Andrew FSJ4-50B 0.81 1000 0.118 2000 0.176 2500 0.201
Andrew HJ4-50 0.91 1000 0.092 2000 0.137 2500 0.156
Andrew HJ4.5-50 0.92 1000 0.054 2000 0.079 2500 0.089
Andrew HJ5-50 0.916 1000 0.042 2000 0.063 2500 0.071
Andrew HJ7-50A 0.921 1000 0.023 2000 0.034 2500 0.039
Andrew HJ12-50 0.931 1000 0.019 2000 0.029 2000 0.029
Andrew HL4RP-50A 0.88 1000 0.074 2000 0.109 2500 0.123
Andrew LDF4-50A 0.88 1000 0.073 2000 0.107 2500 0.12
