E-1 Coaxial Cable Technical Data Coaxial Cable Technical Data
E-2 PN: 10580-00305 Rev. L MS20xxC UG
Andrew LDF4.5-50 0.89 1000 0.054 2000 0.08 2500 0.091
Andrew LDF5-50A 0.89 1000 0.041 2000 0.061 2500 0.07
Andrew LDF5-50B 0.91 1000 0.041 2000 0.061 2500 0.07
Andrew LDF6-50 0.89 1000 0.028 2000 0.042 2500 0.048
Andrew LDF7-50A 0.88 1000 0.024 2000 0.037 2500 0.043
Andrew LDF12-50 0.88 1000 0.021 2000 0.033 2000 0.033
Andrew VXL5-50 7/8 0.88 1000 0.045 2000 0.066 2500 0.075
Andrew VXL6-50 1-1/4 0.88 1000 0.032 2000 0.048 2500 0.055
Andrew VXL7-50 1-5/8 0.88 1000 0.024 2000 0.037 2500 0.043
Belden RG-8/8A 0.86 1000 0.132 2000 0.33 2500 0.22
Belden RG-9/9A 0.659 1000 0.289 1000 0.289 1000 0.289
Belden RG-17/17A 0.659 1000 0.18 1000 0.18 1000 0.18
Belden RG-55/55A/55B 0.659 1000 0.541 1000 0.541 1000 0.541
Belden RG-58/58B 0.77 1000 0.356 2000 0.528 2500 0.6
Belden RG-58A/58C 0.73 1000 0.594 1000 0.594 1000 0.594
Belden RG-142 0.7 1000 0.43 2000 0.663 2500 0.713
Belden RG-174 0.66 1000 1.115 1000 1.115 1000 1.115
Belden RG-178B 0.695 1000 1.509 1000 1.509 1000 1.509
Belden RG-188 0.69 1000 0.951 1000 0.951 1000 0.951
Belden RG-213 0.66 1000 0.262 1000 0.269 1000 0.269
Belden RG-214 0.659 1000 0.229 1000 0.292 1000 0.292
Belden RG-223 0.66 1000 0.476 1000 0.478 1000 0.478
Cablewave HCC 12-50J 0.915 1000 0.087 2000 0.126 2500 0.137
Cablewave HCC 78-50J 0.915 1000 0.041 2000 0.061 2500 0.066
Cablewave HCC 158-50J 0.95 1000 0.022 2000 0.031 2500 0.033
Cablewave HCC 300-50J 0.96 1000 0.015 1000 0.015 1000 0.015
Cablewave HCC 312-50J 0.96 1000 0.013 1000 0.013 1000 0.013
Cablewave HF 4 1/8 Cu2Y 0.97 1000 0.01 1000 0.01 1000 0.01
Cablewave HF 5 Cu2Y 0.96 1000 0.007 1000 0.007 1000 0.007
Cablewave HF 6 1/8 Cu2Y 0.97 1000 0.006 1000 0.006 1000 0.006
Cellflex LCF78-50JA 0.9 1000 0.039 2000 0.058 2500 0.066
Cellflex LCFS114-50JA 0.9 1000 0.029 2000 0.044 2500 0.051
Cellflex LCF158-50JA 0.9 1000 0.024 2000 0.036 2500 0.042
Cellflex LCF214-50JA 0.88 1000 0.021 2000 0.033 2000 0.033
Cellflex UCF114-50JA 0.89 1000 0.031 2000 0.047 2000 0.047
Table E-1. Coaxial Cable Technical Data (Sheet 2 of 4)
Manufacturer Cable
Prop.
Vel.
Freq
1
Loss
1
Freq
2
Loss
2
Freq
3
Loss
3
