Coaxial Cable Technical Data E-1 Coaxial Cable Technical Data
MS20xxC UG PN: 10580-00305 Rev. L E-3
Comscope CR50 540PE 0.88 1000 0.069 2000 0.103 2500 0.116
Comscope CR50 1070PE 0.88 1000 0.037 2000 0.055 2500 0.064
Comscope CR50 1873PE 0.88 1000 0.022 2000 0.034 2500 0.04
Eupen EC4-50-HF 1/2 0.82 1000 0.108 2000 0.161 2500 0.183
Eupen EC4-50 1/2 0.88 1000 0.074 2000 0.109 2500 0.121
Eupen EC4.5-50 5/8 0.88 1000 0.056 2000 0.083 2500 0.094
Eupen EC5-50 7/8 0.88 1000 0.04 2000 0.058 2500 0.066
Eupen EC6-50 1-1/4 0.88 1000 0.028 2000 0.043 2500 0.048
Eupen EC7-50 1-5/8 0.88 1000 0.024 2000 0.037 2500 0.042
Eupen EC7-50A 1-5/8 0.89 1000 0.023 2000 0.035 2500 0.039
Eupen EC12-50 2-1/4 0.88 1000 0.022 2000 0.034 2500 0.039
Nk Cables RF1/2-50 0.88 1000 0.073 2000 0.107 2500 0.127
Nk Cables RF1/2-50GHF 0.88 1000 0.073 2000 0.107 2500 0.127
Nk Cables RF1/2-50BHF 0.88 1000 0.073 2000 0.107 2500 0.127
Nk Cables RF5/8-50 0.88 1000 0.051 2000 0.075 2500 0.087
Nk Cables RF5/8-50GHF 0.88 1000 0.051 2000 0.075 2500 0.087
Nk Cables RF5/8-50BHF 0.88 1000 0.051 2000 0.075 2500 0.087
Nk Cables RF7/8-50 0.88 1000 0.04 2000 0.059 2500 0.07
Nk Cables RF7/8-50GHF 0.88 1000 0.04 2000 0.059 2500 0.07
Nk Cables RF7/8-50BHF 0.88 1000 0.04 2000 0.059 2500 0.07
Nk Cables RF1 5/8-50 0.88 1000 0.024 2000 0.036 2500 0.042
Nk Cables RF1 5/8-50GHF 0.88 1000 0.024 2000 0.036 2500 0.042
Nk Cables RF1 5/8-50BHF 0.88 1000 0.024 2000 0.036 2500 0.042
Nk Cables RF2 1/4-50 0.88 1000 0.021 2000 0.032 2500 0.041
Nk Cables RF2 1/4-50GHF 0.88 1000 0.021 2000 0.032 2500 0.041
Nk Cables RF2 1/4-50BHF 0.88 1000 0.021 2000 0.032 2500 0.041
Nk Cables RFF3/8-50 0.81 1000 0.147 2000 0.218 2500 0.25
Nk Cables RFF3/8-50GHF 0.81 1000 0.147 2000 0.218 2500 0.25
Nk Cables RFF3/8-50BHF 0.81 1000 0.147 2000 0.218 2500 0.25
Nk Cables RFF1/2-50 0.82 1000 0.112 2000 0.167 2500 0.19
Nk Cables RFF1/2-50GHF 0.82 1000 0.112 2000 0.167 2500 0.19
Nk Cables RFF1/2-50BHF 0.82 1000 0.112 2000 0.167 2500 0.19
Nk Cables RFF7/8-50 0.88 1000 0.04 2000 0.066 2500 0.076
Nk Cables RFF7/8-50GHF 0.88 1000 0.04 2000 0.066 2500 0.076
Nk Cables RFF7/8-50BHF 0.88 1000 0.04 2000 0.066 2500 0.076
Table E-1. Coaxial Cable Technical Data (Sheet 3 of 4)
Manufacturer Cable
Prop.
Vel.
Freq
1
Loss
1
Freq
2
Loss
2
Freq
3
Loss
3
