File Management 5-5 File Menu
MS20xxC UG PN: 10580-00305 Rev. L 5-13
Recall Menu
This menu and its dialog box are used to select the location from which the VNA Master
recalls a file. Select folders or locations with the Up/Down arrow keys or the rotary knob.
Key Sequence: File > Recall
Use these menu keys to change the way files are listed in the Recall dialog
box. Navigate to the desired file, then press Enter to recall.
When recalling a saved setup, all current instrument settings are replaced by
the stored setup information. When recalling a saved measurement and
multiple traces are displayed, parameter settings shown on the instrument
screen may reflect those of the recalled trace or the active trace, depending
on the measurement mode or other factors.
Sort By
Name Type Date: Press this submenu key to choose the item by which
folders and files are sorted in the Recall dialog box.
Sort Order
Ascend Descend: Press this key to toggle the sort order of the file list
between Ascending and Descending.
File Type: Press this key to open the Select File Type list box. Press the
desired file type on the list, then press Enter to apply the selection. JPEG
image files cannot be recalled and are not listed.
Alternatively, you can select directly from the Filetype drop down list in the
Recall dialog box.
Refresh Directories: Press this key to update the file list after connecting or
disconnecting an external USB drive.
Figure 5-14. Recall Menu
Sort By
Name Type Date
Sort Order
Ascend Descend
File Type
ALL
Refresh
Directories
Recall
