Anritsu VNA Master MS2026C User Manual

Waveguide Data F-4 Flange Compatibility
MS20xxC UG PN: 10580-00305 Rev. L F-3
F-4 Flange Compatibility
Table F-3. Universal Flange Compatibility (1 of 3)
Calibration
Component
Part Number
Start
Frequency
(GHz)
Stop
Frequency
(GHz)
Waveguide
Type
Flange
Type
Compatible
Flanges
xxUM40 3.300 4.900 WR229
WG11A
UnivM-229 PDR40
xxUM48 3.950 5.850 WR187
WG12
UnivM-187 CAR48
PAR48
UAR48
PDR48
xxUM58 4.900 7.050 WR159
WG13
UnivM-159 CAR58
PAR58
UAR58
PDR58
xxUM70 5.850 8.200 WR137
WG14
UnivM-137 CAR70
PAR70
UAR70
PDR70
xxUM84 7.050 10.000 WR112 WG15 UnivM-112 CBR84
UBR84
PBR84
PDR84
xxUM100 8.200 12.400 WR90 WG16 UnivM-90 CBR100
UBR100
PBR100
PDR100
xxUM120 10.000 15.000 WR75 WG17 UnivM-75 CBR120
UBR120
PBR120
PDR120
xxUM140 12.400 18.000 WR62 WG18 UnivM-62 CBR140
UBR140
PBR140
PDR140
xxUM220 17.000 26.500 WR42 WG20 UnivM-42 CBR220
UBR220
PBR220
PDR220
xxUA229 3.300 4.900 WR229
WG11A
UnivUS-229 CPR229F
CPR229G
UG-1350/U
UG-1351/U
UG-1726/U
UG-1727/U
