F-5 Waveguide Technical Data Waveguide Data
F-8 PN: 10580-00305 Rev. L MS20xxC UG
Waveguide Technical Data
Table F-7. Waveguide Technical Data (Sheet 1 of 2)
Waveguide
Type/Model
Start Frequency
(GHz)
Stop Frequency
(GHz)
Cutoff
Frequency
(GHz)
Mid-Band Loss
(dB/m)
WR229, WG11A 3.300 4.900 2.577 0.0374
WR187, WG12 3.950 5.850 3.152 0.0515
WR159, WG13 4.900 7.050 3.711 0.0591
WR137, WG14 5.850 8.200 4.301 0.0738
WR112, WG15 7.050 10.000 5.259 0.1024
WR102 7.000 11.000 5.786 0.1083
WR90, WG16 8.200 12.400 6.557 0.1578
WR75, WG17 10.000 15.000 7.868 0.1913
WR67 11.000 17.000 8.578 0.2159
WR62, WG18 12.400 18.000 9.486 0.2411
WR51, WG19 15.000 22.000 11.574 0.3691
WR42, WG20 17.000 26.500 14.047 0.5200
Andrew
EW17 1.700 2.400 1.364 0.012
EW20 1.900 2.700 1.57 0.015
EW28 2.600 3.400 2.2 0.021
EW34 3.100 4.200 2.376 0.0223
EW37 3.300 4.300 2.790 0.0292
EW43 4.400 5.000 2.780 0.0289
EW52 4.600 6.425 3.650 0.042
EW63 5.580 7.125 4.000 0.0453
EW64 5.300 7.750 4.320 0.052
EW77 6.100 8.500 4.720 0.061
EW85 7.700 9.800 6.460 0.1086
EW90 8.300 11.700 6.500 0.108
EW127 10.000 13.250 7.670 0.124
EW132 11.000 15.350 9.220 0.17
EW180 14.000 19.700 11.150 0.1939
EW220 17.000 23.600 13.340 0.2822
