Anritsu VNA Master MS2026C User Manual

Waveguide Data F-5 Waveguide Technical Data
MS20xxC UG PN: 10580-00305 Rev. L F-9
Cablewave
WE37 3.600 4.200 2.830 0.0269
WE46 4.400 5.000 3.000 0.0354
WE61 5.925 6.425 3.600 0.0390
WE65 6.425 7.125 4.000 0.0453
WE70 7.125 7.750 4.300 0.0404
WE78 7.125 8.500 4.670 0.0446
WE108 10.500 11.700 6.570 0.0978
WE130 11.700 13.250 7.430 0.1142
WE150 14.000 15.350 8.600 0.1398
WE191 17.700 19.700 10.680 0.1952
RFS Cablewave
E20 1.700 2.300 1.38 0.012
E30 2.300 3.100 1.8 0.016
E38 3.000 4.200 2.4 0.025
E46 3.650 5.000 2.88 0.028
ES46 3.900 5.000 3.08 0.036
E60 4.500 6.425 3.65 0.045
E65 5.000 7.125 4.01 0.05
E78 5.900 8.500 4.72 0.06
E105 8.100 11.700 6.49 0.09
E130 9.300 13.250 7.43 0.12
E150 10.800 15.350 8.64 0.15
E185 13.700 19.700 11.06 0.2
E220 16.700 23.600 13.36 0.29
Table F-7. Waveguide Technical Data (Sheet 2 of 2)
Waveguide
Type/Model
Start Frequency
(GHz)
Stop Frequency
(GHz)
Cutoff
Frequency
(GHz)
Mid-Band Loss
(dB/m)
