Antelope Pico Camera

Antelope Camera Systems

2.4 Setup Procedure

1. Connect the multi colored COAXPress cables to the camera head and the CCU according

to the connector numbering and color. Make sure you connect the camera head connector I

to connector I/R on the CCU, camera head connector II to connector II/G and connector III to

connector III/B on the CCU.

2. Connect the OCP via RS-422 cable / DATA LAN to Remote Port on CCU

3. Connect the OCP via LAN to the OCP Port on the RCP

4. Connect motors to camera head

5. Turn on the CCU using the On/Off Switch (46)

6. Remotes start and are ready to use

NOTE: The port addresses of the other connected controllers must be set to the values

shown in the CCU touchscreen display (44) .

2.5 Attaching a Lens

1. Remove the mount cover from the lens mount by turning the lens mount frame counterclockwise.

2. Align the lens with the lens mount of the camera, and turn it clockwise until it is secured.
