Operational Control Panel (OCP)
61
Antelope Camera Systems
Menu
Submenu
Item
Values /Function
USER MCC 1
user MM preset
USER MCC 2
user MM preset
USER MCC 3
user MM preset
USER MCC 4
user MM preset
RGB SETTINGS
RED GAIN
[-500 - 500]
GREEN GAIN
[-500 - 500]
BLUE GAIN
[-500 - 500]
RED PEDESTAL
[-2047 - 2048]
GREEN PEDESTAL
[-2047 - 2048]
BLUE PEDESTAL
[-2047 - 2048]
SATURATION and MASTER BLACK
SATURATION
[-128 - 127]
MASTER BLACK
[-2047 - 2048]
MINI MOTOR CONTROL
IRIS
ACTIVATE: [ON, OFF] REVERSE: [ON, OFF],
SPEED:[0.1 - 3], Ref. - CALIBRATE IRIS
FOCUS
ACTIVATE: [ON, OFF] REVERSE: [ON, OFF],
SPEED:[0.1 - 3], Ref. - CALIBRATE FOCUS
ZOOM
ACTIVATE: [ON, OFF] REVERSE: [ON, OFF],
SPEED:[0.1 - 3], Ref. - CALIBRATE ZOOM
ENGINEER MENU
DEFLICKER EXPERT
STATUS
[ON, OFF]
FREQUENCY
[50 - 100]
VBOOST
[ON, OFF]
MODULE
[Standalone, Integrated]
REBOOT
reboots Deflicker
VIDEO MODE
[720p60, 720p50, 720p59, 1080p23, 1080p24,
1080p25, 1080p29, 1080p30, 1080p50, 1080p59,
1080p60, 1080i50, 1080i59, 1080i60]
FRQ. SHIFT
[-233 - 517]
MOTOR ADJUST
MOTORS LOC
[CAM HEAD, CCU]
MODE
[Encoder, FREE RUN, DC]
IRIS SPEED
[0%-100%]
IRIS CT. LOC
[CCU, OCP]
FOCUS SPEED
[0%-100%]
FOC. CT. LOC
[CCU, OCP]
ZOOM SPEED
[0%-100%]
ZOOM CT. LOC
[CCU, OCP]
DC ZOOM REL
[ABSOLUTE, RELATIVE]
MATRIX
YR
[-512 - 512]
YG
[-512 - 512]
