AS64 series AC servo drive Function codes
-132-
Modbus address
1604, 1605
CANopen address
0x2302, 0x00
P3.03
1
Data size
16bit
Data format
HEX
Modbus address
1606, 1607
CANopen address
0x2303, 0x00
P3.04
1
Data size
16bit
Data format
HEX
Modbus address
1608, 1609
CANopen address
0x2304, 0x00
P3.05
1
Data size
16bit
Data format
HEX
Modbus address
1610, 1611
CANopen address
0x2305, 0x00
P3.06
1
Data size
16bit
Data format
HEX
Modbus address
1612, 1613
CANopen address
0x2306, 0x00
P3.07
1
Data size
16bit
Data format
HEX
Modbus address
1614, 1615
CANopen address
0x2307, 0x00
P3.10
1
Output of digital 1
Setting range
Default
Unit
Applicable
mode
0x000–0x11F
0x001
-
P
S
T
This parameter specifies the output of digital 1. It is in the hexadecimal format.
In the expression of 0x*——, * indicates the valid mode, the value 0 indicates the input is valid
when the optical coupler is conductive, while the value 1 indicates the input is valid when the
optical coupler is not conductive.
In the expression of 0x—**, ** indicate function settings. The detailed function settings are listed
in the following.
