AS64 series AC servo drive Function codes
-159-
Modbus address
1920, 1921
CANopen address
0x243C, 0x00
P4.61
1
Frequency-division
denominator of
external grating
ruler
Setting range
Default
Unit
Applicable
mode
1–(2
31
-1)
10000
-
P
This parameter specifies the frequency-division denominator of the external grating ruler. It
corresponds to the grating ruler pulses needed for each motor rotation.
P4.61
1
Data size
32bit
Data format
DEC
Modbus address
1922, 1923
CANopen address
0x243D, 0x00
P4.62
1
Reverse external
grating ruler count
Setting range
Default
Unit
Applicable
mode
0–1
0
-
P
This parameter specifies whether to reverse the count from the external grating ruler.
Setting
Meaning
[0]
Use the count from the external grating ruler directly.
1
Reverse the count from the external grating ruler and then
use the reversed count.
P4.62
1
Data size
16bit
Data format
DEC
Modbus address
1924, 1925
CANopen address
0x243E, 0x00
P4.64
1
Hybrid control
deviation limit
Setting range
Defaul
t
Unit
Applicable
mode
1–2
27
160000
reference unit
P
In fully-closed loop control, there is a tolerance between the reference unit corresponding to the
encoder feedback position and user reference unit corresponding to the grating ruler feedback
position. The tolerance is called hybrid-control deviation, specified by R0.05. If R0.05 exceeds the
setting of this parameter, the drive reports fault Er22-1.
P4.64
1
Data size
32bit
Data format
DEC
Modbus address
1928, 1929
CANopen address
0x2440, 0x00
P4.65
1
Threshold for hybrid-
control deviation
clearing
Setting range
Default
Unit
Applicable
mode
0–100
0
rotations
P
This parameter specifies the condition for clearing the hybrid-control deviation. When the motor
rotation number reaches the specified one, the hybrid-control deviation is cleared. The value 0
indicates the hybrid-control deviation is not cleared.
P4.65
1
Data size
16bit
Data format
DEC
Modbus address
1930, 1931
CANopen address
0x2441, 0x00
