AS64 series AC servo drive Function codes
-160-
P4.67
1
Signal source of
pulse feedback
output
Setting range
Default
Unit
Applicable
mode
0–1
0
-
P
This parameter specifies the signal source of pulse feedback output when the fully-closed loop
function is enabled in position mode.
Setting
Meaning
[0]
Encoder
1
Grating ruler
P4.67
1
Data size
16bit
Data format
DEC
Modbus address
1934, 1935
CANopen address
0x2443, 0x00
P4.68
1
External grating
ruler (or encoder 2)
resolution
Setting range
Default
Unit
Applicable
mode
1–(2
31
-1)
10000
pulse
P
This parameter specifies the resolution of the external grating ruler (or second encoder). If the
second encoder is connected, the output is the pulses needed for each encoder rotation.
P4.68
1
Data size
32bit
Data format
DEC
Modbus address
1936, 1937
CANopen address
0x2444, 0x00
P4.69
1
Frequency division
output source
Setting range
Default
Unit
Applicable
mode
0–4
0
-
P
S
T
This parameter specifies the signal source of frequency division output.
Setting
Meaning
[0]
Normal frequency division output
1
Second encoder
2
Input from quadrature pulses in phases A and B
3
Internal virtual shaft
4
First encoder (valid only for incremental encoders)
P4.69
1
Data size
32bit
Data format
DEC
Modbus address
1938, 1939
CANopen address
0x2445, 0x00
P4.70
1
External grating ruler (or
encoder 2) phase-Z
signal type
Setting
range
Default
Unit
Applicable
mode
0–3
0
-
P
S
T
The width for a phase-Z signal can be 1/4, 1/2, or 1/1. The starting phase of a signal in any width
corresponds to 4 types of electrical level in phases A and B. There are total 12 types in
combination. However, to ensure these combinations are applicable and the capture value is
normal in both forward and reverse directions, you need to set the phase-A–phase-B status values
in the high electrical level period of phase-Z signals. For the signals in 1/4 and 1/2 widths, only
