AS64 series AC servo drive Communication
-260-
Display
Fault name
32-bit fault code
(16-bit error code + 16-bit
additional information)
Er10-0
Hardware fault–FPGA fault
7400-1000h
Er10-1
Communication card fault
7500-1001h
Er10-2
Hardware fault–Ground short-connection
fault
2300-1002h
Er10-3
Hardware fault–External input fault
5430-1003h
Er10-4
Hardware fault–Emergency stop fault
5430-1004h
Er10-5
Hardware fault–RS485 communication
fault
7500-1005h
Er10-6
Hardware fault–AC power phase loss
7500-1006h
Er10-7
Hardware fault–Fan fault
7500-1007h
Er10-8
Hardware fault–Regenerative transistor
fault
7500-1008h
Er10-9
Hardware fault–STO phase loss fault
7500-1009h
Er10-a
Hardware fault–STO DPIN1 fault
7500-100ah
Er10-b
Hardware fault–STO DPIN2 fault
7500-100bh
Er11-0
Software fault–Motor control task re-entry
6100-0B00h
Er11-1
Software fault–Periodic task re-entry
6100-0B01h
Er11-2
Software fault–Illegal operation
6100-0B02h
Er12-0
I/O fault–Duplicate digital input
assignment
FF01-0C00h
Er12-2
I/O fault–Pulse input frequency too high
5430-1202h
Er13-0
Main circuit overvoltage
3110-1300h
Er13-1
Main circuit undervoltage
3120-1301h
Er17-0
Drive overload
3230-1700h
Er17-1
Drive overload 2
3230-1701h
Er18-0
Motor overload
3230-1800h
Er18-1
Motor overtemperature
3230-1801h
Er19-0
Speed fault–Overspeed
8400-1900h
Er19-1
Speed fault–CCW overspeed
8400-1901h
Er19-2
Speed fault–CW overspeed
8400-1902h
Er19-3
Speed fault–Overspeed parameter set
incorrectly
6320-1903h
Er19-4
Speed fault–Out-of-control fault
8400-1904h
Er20-0
Speed deviation fault
8400-2000h
Er21-0
Position overtravel–CCW
8500-2100h
Er21-1
Position overtravel–CW
8500-2101h
Er22-0
Position deviation fault
8611-2200h
Er22-1
Hybrid control deviation too large
8611-2201h
