1 Introduction
Qseven
®
modules are compact, highly integrated Single Board
Computers.
Typically a Qseven
®
module consists of a CPU, chipset, memory,
Ethernet controller, BIOS flash, SATA- and USB controller. Interface
controllers or connectors (e.g. RJ45) are implemented on a base board
on to which the Qseven
®
module can be mounted.
In addition to the power supply PCIe, SATA, USB, LPC etc. interfaces
are present on the connector.
Due to the standardized mechanics and interfaces the system can be
scaled arbitrarily. Despite the modular concept the system design is
very flat and compact.
Qseven
®
modules require a carrier board to build a working system.
For evaluation purposes MSC recommends the official Qseven
®
Reference Platform
1.1 Key Features
SoC:
 Intel
®
Atom
™
E3800 Product Family (Bay Trail)
SDRAM:
 up to 4GB DDR3L
 soldered on module
 optionally ECC
Video:
 Dual Channel LVDS 18-bit/24-bit and up to 270MHz pixel clock
Optional embedded Display Port (eDP) depending on BOM variant
 Dual Mode Display Port (DP++) (running as packet organized DP or TMDS signal based HDMI/DVI)
