Avnet Qseven MSC Q7-BT User Manual

MSC Q7-BT MSC_Q7-BT_User_Manual.pdf 79 / 113
Feature
Options
Description
1920x1080
1920x1200
panel will be set on this EDID data and Bios setup options for panel
type, mapping and channels will not be available anymore.
LVDS Mapping
18bit
24bit LDI
24bit FPDI
Select LVDS mapping type
LVDS Spread Spectrum
Disabled, +-0,25% to +-
1,75% in 0,25% steps
Configure the spread spectrum for the LVDS interface.
Number of LVDS channels
Single Channel (1bpp)
Dual Channel (2bpp)
Select number of pixels transferred per clock
Backlight Control
Submenu
Set Backlight settings
7.9.2 Backlight Control
Table 7-28 BIOS Backlight Control Menu
Feature
Options
Description
Backlight_EN Control
Chipset, Always Off
Configures the backlight enable signal. This signal can either be
controlled by chipset, or switched off.
Backlight_EN Polarity
Active Low, Active High
Define the polarity of the backlight enable signal.
PWM Control
EC, Chipset
EC means PWM will be controlled by the board controller. Chipset
means PWM will be controlled by videobios.
PWM Polarity
Active Low, Active High
Backlight PWM signal polarity
PWM Brightness
0-100%
Select the initial brightness value of the flat panel
PWM Frequency
200HZ, 1KHz, 10KHz,
18KHz
Select backlight PWM frequency for brightness control
