Avnet Qseven MSC Q7-BT User Manual

MSC Q7-BT MSC_Q7-BT_User_Manual.pdf 64 / 113
Feature
Options
Description
SW_ALL
SW_ANY
CPU C6 report
Enabled
Disabled
Enable/Disable CPU C6(ACPI C3) report to OS
Package C State limit
C0
C1
C3
C6
C7
No Limit
Package C State limit
7.8.7 PPM Configuration
Table 7-14 BIOS PPM Configuration
Feature
Options
Description
EIST
Enabled
Disabled
Enable or disable Intel
®
Speedstep
For more information see also technotes in Chapter 9.
CPU C state report
Enabled
Disabled
Enable/Disable CPU C state report to OS
Max CPU C-state
C1
C6
C7
This option controls Max C state that the processor will support
7.8.8 IDE Configuration
Table 7-15 BIOS IDE Configuration
Feature
Options
Description
Serial-ATA (SATA)
Enabled
Disabled
Enable / Disable SATA
SATA Test Mode
Enabled
Test Mode enable / disable.
