7.9.5 South Bridge
Table 7-31 BIOS South Bridge
Feature
Options
Description
Azalia HD Audio
Submenu
Azalia HD Audio Configuration settings.
USB Configuration
Submenu
USB Configuration settings
PCI Express Configuration
Submenu
PCI Express Configuration settings
Restore AC Power Loss
Power Off
Power On
Last state
Select AC power state when power is re-applied after a power
failure
High Precision Event Timer.
Enabled
Disabled
Enable or Disable OS support for the High Precision Event Timer. If
disabled, no HPET ACPI table will be created, preventing the OS
from using the HPET
LPC Interface Configuration
LPC; GPIO
Enable LPC interface, or disable it by setting all signals to GPIO
mode. In GPIO mode, all pins will be inputs.
Note: TPM and SIO will not work in GPIO mode. If TPM was
configured before make sure to disable TPM, otherwise Windows 7
can hang during boot.
LPC CLKRUN# support
Enabled, Disabled
Enable LPC clockrun. If enabled, serial IRQ must be set to quiet
mode.
SIO and other LPC devices might cause problems if CLKRUN/quiet
mode is enabled.
LPC Serial IRQ Mode
Continuous, Quiet
Configure Serial IRQ Mode
Global SMI Lock
Enabled
Disabled
Enable or Disable SMI lock.
Bios Read/Write Protection
Enabled
Disabled
Enable or Disable BIOS SPI region read/write protect.
