7.7.2 Hardware Monitoring Measurement
Note: The value shown in the BIOS and EAPI for the CPU temperature, is actually the temperature read by the Board controller from a sensor mounted on the
board.
At elevated temperatures the difference between the BIOS "CPU" temperature and the DTS temperature is 20°C (DTS is 20°C higher)
Table 7-6 BIOS Hardware Monitoring Measurement
Feature
Options
Description
CPU Temperature
Informative
Shows CPU Temperature
Also supported in EAPI
Note: CPU temperature is measured close to the CPU and does
not reflect CPU die temperature
VCore
Informative
Shows the VCore voltage
5V
Infomative
Shows the 5V voltage
5V Standby
Informative
Shows the current 5V Standby voltage
Vbat
Informative
Shows the voltage of the CMOS backup battery.
Note: A value of 2.5V or below would indicate that the CMOS
battery is nearly empty or it could also indicate that no battery is
connected.
CPU Fan Speed
Informative
Shows the current fan speed
