Avnet Qseven MSC Q7-BT User Manual

MSC Q7-BT MSC_Q7-BT_User_Manual.pdf 77 / 113
Feature
Options
Description
1min
5min
Watchdog Action on Reset
Timeout
Reset System
Do Nothing
Assert WDOUT
Select the action that should take place after a reset timeout occurs.
POST Watchdog
Enabled, Disabled
Enable a watchdog during bios POST ( before OS boot).
ATTENTION: if this watchdog is configured with timeouts that are
too agressive, the board might not be able to boot anymore!
Note: Values are valid not until before second boot.
POST Watchdog Timeout
20s …
Set the that is available for the bios to boot. When this time is
exceeded, the EC will try to recover the system through a reset or
powercycle.
POST Watchdog Action
Reset, Powercycle
Configure what action should be taken on a timeout event.
7.8.21 I210 Gigabit Connection Settings
Feature
Options
Description
NIC Configuration
Submenu
Settings for the specified network controller
Link Speed
Auto Negotiaded, 10 Mbps
Half, 10 Mbps Full, 100 Mbps
Half, 100 Mbps Full
Specifies the port speed used for the selected boot protocol
Note: this option is only visible due to Bios code limitiation and has
no effect when changing options.
Wake On Lan
Enabled, Disabled
Enables the server to be powered on by using an in-band magic
packet.
Note: this option is only visible due to Bios code limitiation and has
no effect when changing options
Blink LEDs
1-15s
Identify the physical network port by blinking the associated LED.
