Avnet Qseven MSC Q7-BT User Manual

MSC Q7-BT MSC_Q7-BT_User_Manual.pdf 63 / 113
Feature
Options
Description
Redirection after BIOS POST
Always Enable, Bootloader
The Settings specify if BootLoader is selected then Legacy console
redirection is disabled before booting to Legacy OS. Default value is
Always Enable which means Legaacy console Redirection is
enabled for Legacy OS.
7.8.6 CPU Configuration
Note: Dependent on used CPU, available setup options may vary!!!
Table 7-13 BIOS CPU Menu
Feature
Options
Description
Socket 0 Information
Submenu
Shows different informations about the CPU such as CPU
Signature, Microcode Patch etc.
Limit CPUID Maximum
Enabled
Disabled
Limit the maximum input value for the CPUID instruction to 2.
Enable this as a workaround for old OS that cannot handle Pentium
III or newer CPUs.
Execute Disable Bit
Enabled
Disabled
XD can prevent certain classes of malicious buffer overflow attacks
when combined with a supporting OS
Intel
®
Virtualization
Technology
Enabled
Disabled
When enabled, a VMM can utilize the additional hardware
capabilities provided by Vanderpool Technology
For more information see also technotes in Chapter 9.
Hardware Prefetcher
Enabled
Disabled
To turn on/off the Mid Level Cache (L2) streamer prefetcher.
Adjacent Cache Line
Prefetch
Enabled
Disabled
To turn on/off prefetching of adjacent cache lines.
Power Technology
Energy Efficient
Disabled
Custom
Enable the power management features.
P-STATE Coordination
HW_ALL
Change P-STATE Coordination type
