7.11 Boot
Table 7-36 BIOS Boot Menu
Feature
Options
Description
Setup Prompt Timeout
1-65535sec
Number of seconds to wait for setup activation key. 65535(0xFFFF)
means wait forever.
Bootup NumLock State
On
Off
Select the keyboard NumLock state
Quiet Boot
Enabled
Disabled
Enables/Disables Quiet Boot option
Fast Boot
Enabled
Disabled
Enables/Disables boot with initialization of a minimal set of devices
required to launch active boot option. Has no effect for BBS boot
options.
For more information see also technotes in chapter 9
VGA Support
Auto, EFI Driver
If Auto, only install legacy Oprom with legacy OS and logo would
not be shown during post. EFI driver will still be installed with EFI
OS
USB Support
Disabled, Full Initial, Partial
Initial
If Disabled, all USB devices will NOT be available until after OS
boot. If Partial Initial, USB Mass Storage and specific USB
port/device will NOT be available before OS boot. If Full Initial, all
USB devices will be available in OS and Post.
Note: If disabled, entering Setup will only be possible by performing
a System Reset ( with Reset Button ) during OS Boot, or by clearing
CMOS with the Clear CMOS Jumper.
PS2 Devices Support
Enabled, Disabled
If disabled, PS2 devices will be skipped
Network Stack Driver
Support
Enabled, Disabled
If disabled, Network Stack driver will be skipped
Boot Priority 1
SATA Port 0/1, USB Port 0-
5, eMMC, SD Card, LAN,
UEFI LAN, External Devices
Define which boot device should have the highest boot priority
Note: If the connected device has a legacy and uefi boot path, uefi
will be the higher priority. This can be avoided by filtering UEFI Boot
out
