Avnet Qseven MSC Q7-BT User Manual

MSC Q7-BT MSC_Q7-BT_User_Manual.pdf 89 / 113
Feature
Options
Description
Boot Priority 2
SATA Port 0/1, USB Port 0-
5, eMMC, SD Card, LAN,
UEFI LAN, External Devices
Define which boot device should have the second highest boot
priority
Boot Priority 3
SATA Port 0/1, USB Port 0-
5, eMMC, SD Card, LAN,
UEFI LAN, External Devices
Define which boot device should have the third highest boot priority
Boot Priority 4
SATA Port 0/1, USB Port 0-
5, eMMC, SD Card, LAN,
UEFI LAN, External Devices
Define which boot device should have the fourth highest boot
priority
Allow other devices
Yes, No
If set to no, only devices defined in the advanced boot device
selection items are allowed to boot
Boot option filter
UEFI and Legacy, Legacy
only, UEFI only
This option controls Legacy/UEFI ROMs priority. If set to Legacy
only, then no UEFI Device will be bootable. If set to UEFI only,
UEFI devices will be bootable.
Boot Option #1…
Device x
Sets the system boot order. Please note that UEFI boot entries will
always have the highest priority. This list will be updated during next
boot depending on the settings in the Advanced Boot Device
Selection. Note: The number of available Boot options is dependent
on the devices which are connected.
This windows shows the actual configured boot priority list which is
set in the Boot Priority options above
