MSC Q7-BT MSC_Q7-BT_User_Manual.pdf 41 / 113
4.12 UART
Table 4-15 UART Signal Description
Signal
Pin Type
Signal Level
Available
Power
Tolerance
PU/PD
Description
UART0_TX
O OD
3.3V CMOS
Full On
3.3V
PU 10k 3.3V
UART transmit data
UART0_RX
I
3.3V CMOS
Full On
3.3V
PU 10k 3.3V
UART receive data
4.13 I²C
Table 4-16 I²C Signal Description
Signal
Pin Type
Signal Level
Available
Power
Tolerance
PU/PD
Description
I2C_CLK
O OD
3.3V CMOS
Full On
3.3V
PU 10k 3.3V
General purpose I²C port clock output
I2C_DAT
I/O OD
3.3V CMOS
Full On
3.3V
PU 10k 3.3V
General purpose I²C port data I/O line
4.13.1 I²C Resources on the Module
The I2C interface is available exclusively for off module devices. Thus all addresses are available for customer use.
