7.8.5 Console Redirection Submenu
ANSI, VT100, VT100+, VT-
UTF8
Emulation: ANSI: Extended ASCII char set. VT100: ASCII char set.
VT100+: Extends VT100 to support color, function keys, etc. VT-
UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more
bytes.
9600, 19200, 38400, 57600,
115200
Selects serial port transmission speed. The speed must be matched
on the other side. Long or noisy lines may require lower speeds.
None, Even, Odd, Mark,
Space
A parity bit can be sent with the data bits to detect some
transmission errors. Even: parity bit is 0 if the number of 1's in the
data bits is even. Odd: parity bit is 0 if number of 1's in the data bits
is odd. Mark: parity bit is always 1. Space: Parity bit is always 0.
Mark and Space Parity do not allow for error detection. They can be
used as an additional data bit.
Stop bits indicate the end of a serial data packet. (A start bit
indicates the beginning). The standard setting is 1 stop bit.
Communication with slow devices may require more than 1 stop bit.
Flow control can prevent data loss from buffer overflow. When
sending data, if the receiving buffers are full, a 'stop' signal can be
sent to stop the data flow. Once the buffers are empty, a 'start'
signal can be sent to re-start the flow. Hardware flow control uses
two wires to send start/stop signals.
Enable VT-UF8 Combination Key Support for ANSI/VT100
terminals
With this mode enabled only text will be sent. This is to capture
Terminal data.
Enables or disables extended terminal resolution
On Legacy OS, the number of rows and Columns supported
redirection
VT100, Linux, XTERMR6,
SCO, ESCN, VT400
Select FunctionKey and KeyPad on Putty.
