7.8.20 Module-specific Initialization
Table 7-25 BIOS Module-specific Initialization
Feature
Options
Description
USB Port 1 Mode
Auto
Host,
Device
Select the mode for USB port 1. Choose between host, device, or
auto-detection through USB_ID input signal.
Lan Controller
Enabled
Disabled
Enable or disable the onboard lan controller.
User I2C Support
GPIO-based
Controller-based
Select the type of user I2C support. Select GPIO-based for
Windows OS EAPI driver. Select controller-based for native I2C
driver for Linux and Windows OS
External SMBus Control
Enabled
Disabled
Enable/Disable External SMBus after POST
Shutdown Support
ATX Mode
AT mode
ATX Mode means that the system will be turned off after shutdown.
In AT mode, Windows will not automatically turn off the system, but
instead shows an information message.
Watchdog start on Boot
No
Yes
Start the watchdog after BIOS POST if enabled
Startup Delay
1s
10s
30s
1min
5min
Select the initial delay value. This is an additional one-time delay
before the standard timeout timer is started.
Event timeout
1s
10s
30s
1min
5min
Select the timeout value after which the watchdog will perform its
timeout event action.
Watchdog Action on Event
Timeout
Assert WDOUT
Do Nothing
Select the action that should be initiated after an event timeout
occurs.
Reset Timeout
1s
10s
30s
Select the timeout value after which the watchdog will perform its
reset action. This timeout will start to countdown after the event
timeout expires.
