16. Servicing
16.4 Removal of the front cover
WARNING: Switch off the projector and unplug the power cord before starting the procedure.
Necessary tools
7mmflat screw driver
How to remove
1. Remove the lens. See "Lens removal", page 38.
2. Remove the rubber dust ring from the lens holder.
Image 16-6
Dust ring removal
3. Release the 4 captive screws (1).
300
R5905032 HDX SERIES 01/06/2011
