Barco HDX series - 6.2 Quick Lens Adjustment via LENS key

6. Quick set up adjustment
6.2 Quick Lens Adjustment via LENS key
Quick zoom/focus adjustment
1. Press the LENS key on the remote control or local keypad to open the Zoom/Focus Adjustment menu.
Image 6-1
Zoom/Focus adjustment
2. Use the ▲ or ▼ key to zoom and ◄ or ► key to focus the image.
3. When finished, press EXIT key to return or ENTER to continue to the shift adjustment.
Press the LENS key to switch to another pattern. Different patterns are available.
Quick shift adjustment
1. Press the LENS key on the remote control or local keypad to open the Zoom/Focus Adjustment menu.
Image 6-2
Zoom/Focus adjustment
2. Press ENTER to go to the Shift menu.
