B. Specifications
B.2 Specifications of the HDX W12
Overview
3D ready (optional) active, passive Infitec
AC power 200-240 VAC/50-60 Hz
Accessories
Power cord; wireless/XLR wired rugged remote control
Aspect Ratio 16:10
Brightness uniformity 90% (standard)
Certifications Compliant with UL60950-1 and EN60950-1, complies with FCC rules & regulations, part
15 Class A and CE EN55022 Class A, RoHS
CLO (constant light output) Standard
Color correction P7
Contrast 1,700:1 (standard)
2,400:1 (high contrast mode)
Control - XLR wired, IR, RS-232, DMX512 in/out, integrated web browser, Projection Toolset
- optional control over WiFi and GSM/mobile
Customer bulb replace
Yes
Dimensions (WxLxH) 475 x 382 x 725 mm (18.70” x 14.96” x 28.54”)
Dissipation BTU
max. 8,871 BTU/h
DMX 512
Standard
Input Resolutions
from NTSC up to QXGA (2,048x1,536)
Inputs
SDI/HDSDI/Dual HDSDI/3G
integrated web server Yes
Lamp
2.5kW xenon
Lamp house, quick replace Yes
Lamp lifetime (typical)
2,500 hours
Lamp warranty (field replace/
factory replace)
90 days, 500 hours / pro rata 1000 hours
Lens range
TLD
0.73:1 ; 1.2:1 ; 1.25-1.6:1; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8-4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1
Lens type
TLD+
Light Output 12,000 ANSI lumens
11,000 center lumens
Network connection
10/100 Mb/s Ethernet (on RJ45), WiFi
Noise level (typical at 25°C/77°F)" 50 dB(A)
Operating temperature 0 ~ 40°C / 32 ~ 104°F
operation humidity no condens
0-80%
Optical dowser Standard
Optical lens shift Vertical: -10% to +110%
Horizontal: -30% to +30% on zoom lenses (memorized)
Optional Inputs RGBHV on DVI-I
Orientation table - ceiling - side (portrait) - vertical
Picture-in-picture Up to two sources on-screen simultaneously
Pixel clock 200MHz
Power consumption 2,300 W
STBY <8 W
Projector type WUXGA three-chip DLP digital projector
Resolution 1920x1200 (WUXGA)
R5905032 HDX SERIES 01/06/2011 315
