Specifications, Requirements, and Precautions AW00089317000
10 Basler ace GigE
Specification acA1600-20gm/gc acA1600-60gm/gc acA1920-25gm/gc
Sensor Size
(H x V pixels)
gm: 1626 x 1236
gc: 1624 x 1234
gm: 1602 x 1202
gc: 1600 x 1200
gm: 1920 x 1080
gc: 1920 x 1080
Sensor Type Sony ICX274 AL/AQ
Progressive scan CCD
Global shutter
gm: e2V EV76C570 ABT
gc: e2V EV76C570 ACT
Progressive scan CMOS
Global shutter
Rolling shutter
The shutter mode can be set
via the software.
Aptina MT9P031
Progressive scan CMOS
Rolling shutter
Optical Size 1/1.8" 1/2.5"
Pixel Size 4.4 µm x 4.4 µm 4.5 µm x 4.5 µm 2.2 µm x 2.2 µm
Max. Frame Rate
(at full resolution)
20 fps gm: 60 fps
gc: 60 fps (only, if camera is
set for Bayer RG 8 format
and if GigE connection does
not limit the frame rate)
25 fps
Mono/Color Mono or color (color models include a Bayer pattern RGB filter on the sensor)
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data Formats Mono Models:
Mono 8
Mono 12
Mono 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV) Packed
Color Models:
Mono 8
Bayer BG 8
Bayer BG 12
Bayer BG 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV)
Packed
Color Models:
Bayer RG 8
Bayer RG 12 (*)
Bayer RG 12 Packed (*)
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV)
Packed
[(*) When using one of the
12 bit modes the two least
significant bits are set to
0.]
Color Models:
Mono 8
Bayer BG 8
Bayer BG 12
Bayer BG 12 Packed
YUV 4:2:2 Packed
YUV 4:2:2 (YUYV)
Packed
ADC Bit Depth 12 bits 10 bits, see (*) above 12 bits
Synchronization Via external trigger signal,
via the Ethernet connection,
or free run
Via Ethernet connection, or
free run
Via external trigger signal,
via the Ethernet connection,
or free run
Table 5: General Specifications (acA1600-20gm/gc, acA1600-60gm/gc, acA1920-25gm/gc)
