Basler GigE SERIES User Manual

AW00089317000 Specifications, Requirements, and Precautions
Basler ace GigE 11
Exposure Control Via external trigger signal or
programmable via the
camera API
Programmable via the
camera API
Via external trigger signal or
programmable via the
camera API
Camera Power
Requirements
PoE (Power over Ethernet 802.3af compliant) or
+12 VDC (±10%), < 1% ripple, supplied via the camera’s 6-pin Hirose connector;
Cable must be at least a 26 AWG cable. Max. cable length: 10 m
~ 3.4 W when using Power
over Ethernet
~ 2.9 W @ 12 VDC when
supplied via the camera’s 6-
pin connector
~ 2.5 W when using Power
over Ethernet
~ 2.1 W @ 12 VDC when
supplied via the camera’s 6-
pin connector
~2.5 W when using Power
over Ethernet
~ 2.2 W @ 12 VDC when
supplied via the camera’s 6-
pin connector
I/O Ports 1 opto-isolated input line and 1 opto-isolated output line
Lens Adapter C-mount; CS-mount
Size (L x W x H) 42.0 mm x 29 mm x 29 mm (without lens adapter or connectors)
60.3 mm x 29 mm x 29 mm (with lens adapter and connectors)
Weight < 90 g
Conformity CE (*), UL, FCC, GenICam, GigE Vision, IP30, RoHS, IEEE 802.3af (PoE)
* The CE Conformity Declaration is available on the Basler website:
www.baslerweb.com
Software
 Basler pylon 4 Camera Software Suite:
Available for Windows in 32- and 64-bit versions.
 Basler pylon 3.2.x:
Available for Windows or Linux in 32- and 64-bit versions.
Specification acA1600-20gm/gc acA1600-60gm/gc acA1920-25gm/gc
Table 5: General Specifications (acA1600-20gm/gc, acA1600-60gm/gc, acA1920-25gm/gc)
